Kia Sedona II (2005-2010) k-line rf sig lf sig rr sig lr sig gnd Wiring diagram

This page shows the only wiring diagram for the component.k-line rf sig lf sig rr sig lr sig gnd, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram k-line rf sig lf sig rr sig lr sig gnd (1 of 1)

Wiring diagram k-line rf sig lf sig rr sig lr sig gnd for Kia Sedona II (2005-2010)

Get access

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 B+ IGN BEC-IM BLK WIRE BLU WIRE BLU/ORG WIRE COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT CLUSTER IPM (BEHIND LEFT SIDE OF DASH) JOINT CONNECTOR K-LINE RF SIG LF SIG RR SIG LR SIG GND LEFT FRONT TPMS INITIATOR (LEFT FRONT WHEELWELL) LEFT REAR TPMS INITIATOR (FRONT OF LEFT REAR WHEELWELL) MICOM ORG/ WIRE RED WIRE RED/ORG WIRE RIGHT FRONT TPMS INITIATOR (RIGHT FRONT WHEELWELL) RIGHT REAR TPMS INITIATOR (FRONT OF RIGHT REAR WHEELWELL) TIRE PRESSURE MONITORING MODULE (BEHIND CENTER OF DASH) TPMS IND TREAD IND TREAD IND CHK IND FR FL RR RL WHT WIRE WHT/ORG WIRE YEL/BLK WIRE

Go to component: -> Tire pressure monitoring circuit -> K-LINE RF SIG LF SIG RR SIG LR SIG GND
