Kia Sedona II (2005-2010) imp (instrument panel wiring diagram
This page shows the only wiring diagram for the component.imp (instrument panel, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
imp (instrument panel wiring diagram (1 of 1)
BEC-IF
BLK WIRE
BLK/RED WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN/ORG WIRE
FRONT
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
IMP (INSTRUMENT PANEL
PASS P/SEAT FUSE MODULE) (BEHIND LEFT SIDE OF DASH)
PASSENGER POWER SEAT MODULE (IN FRONT PASSENGER'S SEAT)
PASSENGER POWER SEAT SWITCH
PNK WIRE
PNK/BLK WIRE
REAR REAR FRONT
RECLINING SWITCH SLIDE SWITCH
RIGHT RECLINING MOTOR (IN FRONT PASSENGER'S SEAT)
SLIDE 1
SLIDE 2
TILT 1
TILT 2
WHT WIRE
YEL WIRE
Go to component -> Passenger seat circuit -> IMP (INSTRUMENT PANEL
