Kia Sedona II (2005-2010) head lamp sw in Wiring diagram
This page shows the only wiring diagram for the component.head lamp sw in, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram head lamp sw in (1 of 1)
AUTO
AUTO HEAD PARK OFF
AUTO LIGHT INPUT
AUTO LIGHT, PHOTO SENSOR (TOP CENTER OF DASH)
BCM-FE
BCM-IF
BCM-IM
BEC-IM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
DIMMER, PASSING SWITCH
FOG LAMP IND
FOG LAMP SWITCH
FRONT AREA MODULE (FAM) (LEFT FRONT
GRN WIRE
GRN/ORG WIRE
HEAD LAMP SW IN
HIGH BEAM IND
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL MODULE (IPM) (BEHIND LEFT SIDE OF DASH)
IPS
LEFT FOG LAMP
LEFT HEAD- LAMP
LIGHT SWITCH
LOW HIGH
MEMORY FUSE
MICON
MULTIFUNCTION SWITCH
OF ENGINE COMPT)
OFF
OFF PARK HEAD
ORG/ WIRE
PASS
PASS LOW HIGH
PASS SW IN
PNK WIRE
RED WIRE
RIGHT FOG LAMP
RIGHT HEAD- LAMP
SW IN DIMMER
SW IN FOG LAMP
TAIL LAMP SW IN
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component: -> Headlights circuit -> HEAD LAMP SW IN
