Kia Sedona II (2005-2010) front area module Wiring diagram

This page shows the only wiring diagram for the component.front area module, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram front area module (1 of 1)

Wiring diagram front area module for Kia Sedona II (2005-2010)

Get access

BCM-IF BEC-FE BEC-FF BLK WIRE FRONT AREA MODULE GRN WIRE HORN FUSE HORN RELAY HORN RELAY PANEL MODULE (BEHIND LEFT SIDE OF DASH) BCM-IM HORN SWITCH HOT AT ALL TIMES INSTRUMENT LEFT HORN (LEFT FRONT CORNER OF ENGINE COMPARTMENT) MULTI- FUNCTION SWITCH CLOCK SPRING NCA WIRE RIGHT HORN (RIGHT FRONT CORNER OF ENGINE COMPARTMENT) STEERING WHEEL) YEL WIRE

Go to component: -> Horn circuit -> FRONT AREA MODULE
