Kia Sedona II (2005-2010) door on sw sw in in Wiring diagram
This page shows the only wiring diagram for the component.door on sw sw in in, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door on sw sw in in (1 of 1)
13 7 BATT POWER DOOR LAMP
7 8 HI LO CAN
AUDIO FUSE
BATT POWER
BCM-IF
BCM-IM
BEC-IF
BEC-IM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
DDM FUSIBLE LINK ADM FUSIBLE LINK
DOOR
DOOR LAMP
DOOR ON SW SW IN IN
DOOR OPEN IND
DRIVER DOOR MODULE
GRN WIRE
HI LO
HOT AT ALL TIMES
HOT AT ALL TIMES INSTRUMENT PANEL MODULE (BEHIND LEFT SIDE OF DASH)
ILL
INSTRUMENT CLUSTER
INSTRUMENT ILLUMINATION CIRCUIT
LEFT
LEFT FRONT DOOR LAMP
LEFT STEP LAMP
LEFT VANITY LAMP
MAP LAMP
MAP LAMP SWITCH
MEMORY FUSE
MICOM
ORG/ WIRE
ORG/BLK WIRE
OVERHEAD CONSOLE
PASSENGER DOOR MODULE
PNK WIRE
REAR ROOM LAMP SWITCH
RED WIRE
RED/ORG WIRE
RIGHT
RIGHT FRONT DOOR LAMP
RIGHT STEP LAMP
RIGHT VANITY LAMP
ROOM FUSE
ROOM LAMP
SHUNT CONNECTOR
TAIL GATE OPEN IND
W/ MAP LAMP
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component: -> Courtesy lamps circuit (1 of 2) -> DOOR ON SW SW IN IN
