Kia Sedona II (2005-2010) buzzer rx tx tx backup gnd Wiring diagram

This page shows the only wiring diagram for the component.buzzer rx tx tx backup gnd, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram buzzer rx tx tx backup gnd (1 of 1)

Wiring diagram buzzer rx tx tx backup gnd for Kia Sedona II (2005-2010)

Get access

BACK WARNING BUZZER (BEHIND LEFT END OF DASH) BACK WARNING CONTROL MODULE (NEAR BASE OF RIGHT "C" PILLAR) BEC-IF BLK WIRE BLU WIRE BUZZER RX TX TX BACKUP GND FUSE GRN GRN/ORG WIRE GRN WIRE GRN/ORG WIRE HOT IN ON OR START INSTRUMENT PANEL MODULE (IPM) (BEHIND LEFT SIDE OF DASH) LEFT BACK WARNING SENSOR LEFT CENTER BACK WARNING SENSOR NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE RED WIRE RIGHT BACK WARNING SENSOR RIGHT CENTER BACK WARNING SENSOR RX RX RX TX TX PNK WIRE WHT WIRE WHT/BLK WIRE YEL GRN/ORG WIRE YEL WIRE YEL/BLK WIRE

Go to component: -> Parking assistant circuit -> BUZZER RX TX TX BACKUP GND
