Kia Sedona II (2005-2010) atm solenoid Wiring diagram
This page shows the only wiring diagram for the component.atm solenoid, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram atm solenoid (1 of 1)
ATM KEY LOCK CONTROL MODULE
ATM SOLENOID
BCM-FC FRONT AREA MODULE (LEFT FRONT OF ENGINE COMPT)
BEC-FC
BEC-FE
BEC-FF FRONT AREA MODULE (LEFT FRONT OF ENGINE COMPT)
BEC-IF
BEC-IM
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER POWER SEAT MODULE (IN DRIVER'S SEAT)
ENG FUSE
FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
INSTRUMENT PANEL MODULE (BEHIND LEFT SIDE OF DASH)
K/LOCK FUSE
KEY INTERLOCK RELAY
KEY INTERLOCK SWITCH (UNDER LEFT SIDE OF DASH)
KEY SOLENOID
ORG/ WIRE
P INP
P POS SWITCH
PCM
PNK WIRE
RANGE
STOP LAMP SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
TRANSAXLE RANGE SWITCH (ON TOP OF TRANSAXLE)
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component: -> Shift interlock circuit -> ATM SOLENOID
