Kia Sedona II (2005-2010) 38 37 can high can low Wiring diagram

This page shows the only wiring diagram for the component.38 37 can high can low, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 38 37 can high can low (1 of 1)

Wiring diagram 38 37 can high can low for Kia Sedona II (2005-2010)

Get access

38 37 CAN HIGH CAN LOW BACK UP SIG OUT BACK WARNING CONTROL MODULE (NEAR BASE OF RIGHT "C" PILLAR) BCM-FC BCM-IF BEC-FC BEC-FF BEC-IF BLK PNK/ WIRE BLK WIRE BLU WIRE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM ELECTRO CHROMIC MIRROR (FRONT CENTER OF ROOF) ENG FUSE FRONT AREA MODULE (FAM) (LEFT FRONT OF ENGINE COMPARTMENT) BACK-UP SIGNAL INPUT GRN WIRE HOME LINK HOT IN ON OR START INSTRUMENT PANEL MODULE (IPM) (BEHIND LEFT SIDE OF DASH) IPS LEFT REAR COMBINATION LAMP LEFT BACK-UP LAMP ORG/ WIRE PCM PNK WIRE PNK/ BLK WIRE REAR AREA MODULE (LEFT REAR CORNER OF VEHICLE) RED WIRE RIGHT REAR COMBINATION LAMP RIGHT BACK- UP LAMP TRANSAXLE RANGE SWITCH (ON TOP OF TRANSAXLE) W/ HOME LINK

Go to component: -> Back-up lamps circuit -> 38 37 CAN HIGH CAN LOW
