Kia Sedona II (2005-2010) 13 7 batt power door lamp Wiring diagram

13 7 BATT POWER DOOR LAMP 7 8 HI LO CAN AUDIO FUSE BATT POWER BCM-IF BCM-IM BEC-IF BEC-IM BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE DDM FUSIBLE LINK ADM FUSIBLE LINK DOOR DOOR LAMP DOOR ON SW SW IN IN DOOR OPEN IND DRIVER DOOR MODULE GRN WIRE HI LO HOT AT ALL TIMES HOT AT ALL TIMES INSTRUMENT PANEL MODULE (BEHIND LEFT SIDE OF DASH) ILL INSTRUMENT CLUSTER INSTRUMENT ILLUMINATION CIRCUIT LEFT LEFT FRONT DOOR LAMP LEFT STEP LAMP LEFT VANITY LAMP MAP LAMP MAP LAMP SWITCH MEMORY FUSE MICOM ORG/ WIRE ORG/BLK WIRE OVERHEAD CONSOLE PASSENGER DOOR MODULE PNK WIRE REAR ROOM LAMP SWITCH RED WIRE RED/ORG WIRE RIGHT RIGHT FRONT DOOR LAMP RIGHT STEP LAMP RIGHT VANITY LAMP ROOM FUSE ROOM LAMP SHUNT CONNECTOR TAIL GATE OPEN IND W/ MAP LAMP WHT WIRE YEL WIRE YEL/BLK WIRE
