Kia Sedona I (1998-2006) left left front position fog lamp lamp Wiring diagram
This page shows the only wiring diagram for the component.left left front position fog lamp lamp, which is found in the car Kia Sedona I (1998-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left left front position fog lamp lamp (1 of 1)
AIR CON CONTROL UNIT
BATTERY
BATTERY GROUND
BLK WIRE
CARGO REAR ROOM WIPER LAMP MOTOR
CRUISE CONTROL SWITCH
CRUISE CONTROL UNIT
DATA LINK CONNECTOR
DRIVER SEAT WARMER SWITCH
FRONT DEFROSTER
FRONT WASHER MOTOR
FRONT, REAR DEFROSTER SWITCH
HIGH COOLING FAN RELAY 2
INSTRUMENT CLUSTER
JB-05
LEFT BACK-UP LIGHT
LEFT FRONT TURN LAMP
LEFT HEADLIGHT
LEFT HORN
LEFT LEFT FRONT POSITION FOG LAMP LAMP
LEFT REAR TURN LAMP
LEFT STOPLIGHT
LEFT TAILLAMP
MODE ACTUATOR
NCA WIRE
PANEL LIGHT CONTROL SWITCH
POWERTRAIN CONTROL MODULE
REAR AUX CONTROL SWITCH
REAR HEATER CONTROL SWITCH
REAR HIGH WIPER, MOUNT WASHER STOPLIGHT RELAY
RIGHT FRONT FOG LAMP
RIGHT FRONT TURN LAMP
RIGHT HORN
SHORT CONNECTOR JC-05
SHORT CONNECTOR JC-09
Go to component -> Ground distribution circuit (1 of 3) -> LEFT LEFT FRONT POSITION FOG LAMP LAMP
