Kia Sedona I (1998-2006) knock speed sensor sensor shield Wiring diagram
This page shows the only wiring diagram for the component.knock speed sensor sensor shield, which is found in the car Kia Sedona I (1998-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram knock speed sensor sensor shield (1 of 1)
AUTO A/T LIGHT CHANGE CONTROL LEVER UNIT
BLK WIRE
BRAKE FLUID LEVEL OBD II SENSOR CHECK CONNECTOR
CAMSHAFT POSITION SENSOR
CLOCK
COMBINATION SWITCH
COMBINATION SWITCH (FRONT WIPER, WASHER)
CRANKSHAFT POSITION SENSOR
DRL FLASHER UNIT UNIT AUDIO
ETWIS
FRONT BLOWER RELAY
FRONT FOG LAMP SWITCH
FUEL LID OPENER
HAZARD GLOVE BOX CIGAR SWITCH ILLUMINATION LIGHTER
HEADLIGHT RELAY (HIGH)
IGNITION COIL 3
IGNITION FAILURE SENSOR
IGNITION IGNITION COIL 1 COIL 2
IMMOBILIZER UNIT
JB-01
JB-07
JB-08
JB-14
JB-15
KEYLESS ENTRY RECEIVER
KNOCK SENSOR
KNOCK SPEED SENSOR SENSOR SHIELD
LEFT REAR POWER SOCKET
LEFT REAR ROOM LAMP 1
LEFT REAR ROOM LAMP 3
LEFT SUNVISOR LAMP
NCA WIRE
OVERHEAD CONSOLE
PASSENGER FRONT SEAT POWER WARMER SOCKET SWITCH
RAIN SENSOR
REAR BLOWER CONTROL SWITCH
REAR CIGAR LIGHTER RELAY
REAR WIPER, FRONT WASHER WIPER SWITCH MOTOR
RELAY
RIGHT REAR ROOM LAMP 2
RIGHT REAR ROOM LAMP 4
RIGHT SUNVISOR LAMP
SHORT CONNECTOR JC-08
SHORT CONNECTOR JC-14
SUN ROOF CONTROL UNIT
TRIP COMPUTER
Go to component: -> Ground distribution circuit (2 of 3) -> KNOCK SPEED SENSOR SENSOR SHIELD
