Kia Sedona I (1998-2006) hazard relay Wiring diagram
This page shows the only wiring diagram for the component.hazard relay, which is found in the car Kia Sedona I (1998-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hazard relay (1 of 1)
A/T CHANGE LEVER
A/T CONTROL RELAY
AT FUSE
BLU WIRE
BLU/WHT WIRE
BTN 2 FUSE
BTN 3 FUSE
CHECK CONNECTOR
DOOR LOCK FUSE
DRIVER P/SEAT FUSE
DRIVER POWER SEAT, SEAT WARMER
ETWIS FUEL LID OPENER SWITCH
F/BLOWER FUSE
FLASHER UNIT
FOLDING MIRROR UNIT
FROM C/FAN 2
FRONT BLOWER RELAY
FRONT DEFROSTER RELAY
FRONT FOGLAMP RELAY
FUSE
GRN WIRE
HAZARD FUSE
HAZARD RELAY
HEADLIGHT RELAY (HIGH)
HEADLIGHT RELAY (LOW)
HOT AT ALL TIMES
JB-06
JB-08
JB-09
JB-12
JB-13
JB-14
JB-15
JB-16
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
NCA WIRE
PASSENGER P/SEAT FUSE
PASSENGER POWER SEAT, SEAT WARMER
R/HEATER FUSE
REAR BLOWER RELAY
RED WIRE
SUN ROOF CONTROL UNIT
SUN ROOF FUSE
TNS RELAY
TO AUDIO
TO FRONT CIGAR LIGHTER RELAY (DIAGRAM 5 OF 5)
W/SHIELD FUSE
WHT WIRE
YEL WIRE
Go to component: -> Power distribution circuit (3 of 5) -> HAZARD RELAY
