Kia Sedona I (1998-2006) defogger system pnk wiring diagram
This page shows the only wiring diagram for the component.defogger system pnk, which is found in the car Kia Sedona I (1998-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
defogger system pnk wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DEFOGGER SYSTEM
DEFOGGER SYSTEM PNK WIRE
FOLDING MIRROR CIRCUIT
FUSE
GRN WIRE
HOT IN ACC OR ON JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
JB-16
LEFT
LEFT POWER MIRROR MOTOR (ON LEFT FRONT DOOR)
LEFT RIGHT
ORG/ WIRE
POWER MIRROR SWITCH
RED WIRE
RIGHT
RIGHT LEFT
RIGHT MIRROR DE- FROSTER
RIGHT POWER MIRROR MOTOR (ON RIGHT FRONT DOOR)
UP DOWN DOWN UP
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit -> DEFOGGER SYSTEM PNK WIRE
