Kia Sedona I (1998-2006) combination air bag switch control unit sc-06 wiring diagram
This page shows the only wiring diagram for the component.combination air bag switch control unit sc-06, which is found in the car Kia Sedona I (1998-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
combination air bag switch control unit sc-06 wiring diagram (1 of 1)
A/T CHANGE AUTO LIGHT LEVER CONTROL UNIT
A/T CHANGE LEVER
AIR CON RELAY
BLK WIRE
BLU WIRE
C/FAN 1 FUSE
C/FAN 2 FUSE
COMBINATION AIR BAG SWITCH CONTROL UNIT SC-06
COOLING FAN RELAY (LOW)
COOLING FAN RELAY 1 (HIGH)
CRUISE CONTROL SWITCH PNK PNK WIRE
CRUISE DATA LINK CONTROL CONNECTOR UNIT
DEF FUSE
DRL ETWIS UNIT
ENG FUSE
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
FROM HORN
FROM IGNITION SWITCH (DIAGRAM 1 OF 5)
FROM SC-06 (DIAGRAM 2 OF 5)
FUEL PUMP RELAY
GRN WIRE
IGNITION ABS EBD, FAILURE CONTROL WARNING SENSOR UNIT RELAY
IMMOBILIZER UNIT
INPUT SENSOR
INSTRUMENT TRIP AIRCON CLUSTER COMPUTER CONTROL UNIT
JB-01 JB-03
JB-02
JB-04
JB-07
JB-08
JB-12
JB-14
JB-15
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
METER FUSE
OUTPUT SENSOR
PNK PNK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE
REAR DEFROSTER RELAY
SC-03
SPEED SENSOR
STOPLIGHT SWITCH
TO BTN 3
TO ENGINE COMPT FUSE/ RELAY BOX (DIAGRAM 2 OF 5)
TRANSAXLE COMBINATION SWITCH RANGE SWITCH
TURN FUSE A/BAG FUSE
WHT WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (2 of 5) -> COMBINATION AIR BAG SWITCH CONTROL UNIT SC-06
