Kia Rio IV facelift (2020-2024) wiper high relay Wiring diagrams
This page contains all the electrical diagrams for the component. wiper high relay, in which he is found in the car Kia Rio IV facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
wiper high relay wiring diagram (1 of 2)
B-CAN HIGH
B-CAN LOW
BCM
BLADE POS SW IN
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
FRONT WASHER SW
FRONT WASHER SWITCH
FRONT WIPER SW
GRN WIRE
GROUND
GRY WIRE
HIGH SWITCH
HIGH WIPER RELAY CONTROL
INT (VOLUME)
INT SWITCH
LOW SWITCH
LOW WIPER RELAY CONTROL
MIST SWITCH
MULTI- FUNCTION SWITCH
ORG/ WIRE
PCM
PNK WIRE
REAR WIPER/ WASHER CIRCUIT
RED WIRE
VOL 1 (FAST) VOL 2
VOL 3
VOL 4
VOL 5 (SLOW)
WASHER MOTOR
WHT WIRE
WIPER FUSE
WIPER HIGH RELAY
WIPER LOW
WIPER LOW RELAY
WIPER LOW SWITCH
WIPER SIG
YEL WIRE
Go to component -> Front wiper/washer circuit, w/ bcm (1 of 2) -> WIPER HIGH RELAY
wiper high relay wiring diagram (2 of 2)
BLK WIRE
BLOWER RELAY
BRAKE FLUID LEVEL SENSOR
BURGLAR ALARM HORN
COOLING FAN MOTOR
E/R JUNCTION BLOCK
ESC CONTROL MODULE
EXTERNAL BUZZER
FRONT WIPER MOTOR
HOOD SWITCH
HORN
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION LOCK, CLUTCH SWITCH
LEFT FRONT FOG LAMP
LEFT HEADLAMP
NEUTRAL SWITCH
OIL PRESSURE SWITCH
PASSENGER OCCUPANT DETECTION SENSOR
PASSENGER SEAT BELT BUCKLE SWITCH
PCM
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
SRS CONTROL MODULE
STOP LAMP SWITCH
W/ BCM
W/ PROJECTION HEADLAMPS
W/ SMART KEY
W/O PROJECTION HEADLAMPS
WASHER LEVEL SENSOR
WASHER MOTOR
WIPER HIGH RELAY
WIPER LOW RELAY
Go to component -> Ground distribution circuit (4 of 4) -> WIPER HIGH RELAY
