Kia Rio IV facelift (2020-2024) trunk antenna gnd wiring diagram
This page shows the only wiring diagram for the component.trunk antenna gnd, which is found in the car Kia Rio IV facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
trunk antenna gnd wiring diagram (1 of 1)
A/T
A/T SHIFT LEVER
B SIG
BLK WIRE
BLU WIRE
BRAKE SWITCH FUSE
BRN WIRE
BUMPER ANTENNA GND
BUMPER ANTENNA PWR
C-CAN
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
GND PWR 2
GND SIG 1
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P JUNCTION BLOCK
I/P-C
IGNITION LOCK SWITCH
IGNITION LOCK, CLUTCH SWITCH
IMMO ANTENNA GND
IMMO ANTENNA PWR
IMMO IND
INSTRUMENT CLUSTER
INTERIOR 1 GND
INTERIOR 1 PWR
INTERIOR 2 GND
INTERIOR 2 PWR
KEY OUT IND
M/T
MICOM
ORG/ WIRE
OUTSIDE HANDLE ANTENNA AST GND
OUTSIDE HANDLE ANTENNA AST PWR
OUTSIDE HANDLE ANTENNA DRV GND
OUTSIDE HANDLE ANTENNA DRV PWR
P POSITION SWITCH
PNK WIRE
POWER CONNECTOR
RED WIRE
ROOM LAMP FUSE
SMART KEY ANTENNA (INTERIOR 1)
SMART KEY ANTENNA (INTERIOR 2)
SMART KEY BUMPER ANTENNA
SMART KEY CONTROL MODULE (RIGHT SIDE OF HVAC CASE)
SMART KEY TRUNK ANTENNA
TRANSCEIVER/
TRUNK ANTENNA GND
TRUNK ANTENNA PWR
WHT WIRE
YEL WIRE
Go to component -> Immobilizer circuit, w/ smart key system (3 of 3) -> TRUNK ANTENNA GND
