Kia Rio IV facelift (2020-2024) sunroof fuse Wiring diagrams
This page contains all the electrical diagrams for the component. sunroof fuse, in which he is found in the car Kia Rio IV facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sunroof fuse (1 of 2)
BLK WIRE
BLU WIRE
BRAKE SWITCH FUSE
DRIVER SAFETY POWER WINDOW MODULE
FROM B+2 FUSE (DIAGRAM 1 OF 8)
FROM ROOM LAMP FUSE (DIAGRAM 2 OF 8)
FROM WIPER RR FUSE (DIAGRAM 6 OF 8)
FRONT SEAT WARMER CONTROL MODULE
GLOVE BOX LAMP)
HATCHBACK
I/P-A
I/P-B
I/P-C
IMMO FUSE
IMMOBILIZER MODULE
INSTRUMENT CLUSTER
LEFT FRONT VANITY LAMP
ORG/ WIRE
OVERHEAD CONSOLE LAMP
PNK WIRE
POWER WINDOW RELAY
RED WIRE
RIGHT FRONT VANITY LAMP
ROOM LAMP
ROOM LAMP RELAY
S/HEATER FUSE
SAFETY P/WINDOW FUSE
SEDAN
SMART KEY CONTROL MODULE
SMART KEY FUSE
STOP LAMP SWITCH
SUNROOF FUSE
SUNROOF MOTOR
TRUNK ROOM LAMP
W/ BCM
W/ OVERHEAD CONSOLE
W/ SUNROOF
W/ SUNVISOR
W/O BCM
W/O OVERHEAD CONSOLE
W/O SMART KEY
W/O SUNROOF
W/O SUNVISOR
WHT WIRE
Go to component -> Power distribution circuit (3 of 8) -> SUNROOF FUSE
Wiring diagram sunroof fuse (2 of 2)
BCM
BLK WIRE
BLU WIRE
BRN WIRE
CLOSE SWITCH
DRIVER SAFETY POWER WINDOW MODULE
ENABLE
GLASS STATUS SIGNAL
GRN WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON
I/P JUNCTION BLOCK
I/P-C
I/P-D
MEMORY POWER
MODULE 5 FUSE
OPEN SWITCH
ORG/ WIRE
OVERHEAD CONSOLE LAMP
SAFETY POWER WINDOW ENABLE
SIG A
SIG B
SIG C
SUNROOF FUSE
SUNROOF MOTOR (CENTER FRONT OF ROOF)
SUNROOF OPEN SWITCH
SUNROOF SWITCH
TILT UP SWITCH
W/ BCM
W/O BCM
WHT WIRE
Go to component -> Power top/sunroof circuit -> SUNROOF FUSE
