Kia Rio IV facelift (2020-2024) pass side impact press sens low Wiring diagram
This page shows the only wiring diagram for the component.pass side impact press sens low, which is found in the car Kia Rio IV facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass side impact press sens low (1 of 1)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
DRIVER CURTAIN AIR BAG
DRIVER FRONT SIDE IMPACT SENSOR
DRIVER SEAT BELT ANCHOR PRETENSIONER
DRIVER SEAT BELT PRETENSIONER
DRIVER SIDE AIR BAG
DRIVER SIDE IMPACT PRESSURE SENSOR
DRV ANCHOR PRETENSIONER HIGH
DRV ANCHOR PRETENSIONER LOW
DRV CURTAIN AIR BAG HIGH
DRV CURTAIN AIR BAG LOW
DRV FRONT SIDE IMPACT SENS HIGH
DRV FRONT SIDE IMPACT SENS LOW
DRV SEAT BELT PRETENSIONER HIGH
DRV SEAT BELT PRETENSIONER LOW
DRV SIDE AIR BAG HIGH
DRV SIDE AIR BAG LOW
DRV SIDE IMPACT PRESS SENS HIGH
DRV SIDE IMPACT PRESS SENS LOW
GRN WIRE
GRY WIRE
ORG/ WIRE
PASS AIR BAG (ACTIVE) HIGH
PASS AIR BAG (ACTIVE) LOW
PASS ANCHOR PRETENSIONER HIGH
PASS ANCHOR PRETENSIONER LOW
PASS CURTAIN AIR BAG HIGH
PASS CURTAIN AIR BAG LOW
PASS FRONT SIDE IMPACT SENS HIGH
PASS FRONT SIDE IMPACT SENS LOW
PASS SEAT BELT BUCKLE SW
PASS SEAT BELT PRETENSIONER HIGH
PASS SEAT BELT PRETENSIONER LOW
PASS SIDE AIR BAG HIGH
PASS SIDE AIR BAG LOW
PASS SIDE IMPACT PRESS SENS HIGH
PASS SIDE IMPACT PRESS SENS LOW
PASSENGER AIR BAG (ACTIVE)
PASSENGER CURTAIN AIR BAG
PASSENGER FRONT SIDE IMPACT SENSOR
PASSENGER SEAT BELT ANCHOR PRETENSIONER
PASSENGER SEAT BELT BUCKLE SWITCH
PASSENGER SEAT BELT PRETENSIONER
PASSENGER SIDE AIR BAG
PASSENGER SIDE IMPACT PRESSURE SENSOR
RED WIRE
SRS CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE)
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> PASS SIDE IMPACT PRESS SENS LOW
