Kia Rio IV facelift (2020-2024) off up Wiring diagram
This page shows the only wiring diagram for the component.off up, which is found in the car Kia Rio IV facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off up (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DIRECTION
DOOR LOCK SWITCH
DOOR LOCKS SYSTEM
DOWN
DOWN OFF
DRIVER SAFETY POWER WINDOW MODULE
ENABLE
GRN WIRE
GRY WIRE
GRY/ORG WIRE
ILL
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SWITCH
OFF
OFF DOWN
OFF UP
ORG/ WIRE
PASSENGER POWER WINDOW MOTOR
PASSENGER POWER WINDOW SWITCH
PNK WIRE
PULSE
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SWITCH
SAFETY WINDOW ECU
SW SIG
UP OFF
VCC
WHT WIRE
YEL WIRE
Go to component -> Power windows circuit, w/ driver auto up/down & safety power windows (2 of 2) -> OFF UP
