Kia Rio IV facelift (2020-2024) main relay ctrl Wiring diagram
This page shows the only wiring diagram for the component.main relay ctrl, which is found in the car Kia Rio IV facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram main relay ctrl (1 of 1)
A/C RELAY CTRL
AIR CONDITIONING SYSTEM
ALT LIN
BATTERY SENS
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRAKE SW IN
BRAKE TEST SW
BRN WIRE
BRN/ORG WIRE
C-CAN HIGH
C/FAN RLY CTRL HI
CCV CTRL
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
CVVT EXHAUST CTRL
CVVT INTAKE CTRL
DEFOGGER SYSTEM
DEFROST HIGH
EGR MOTOR (-)
ENG RPM
FP RELAY CTRL
GRN WIRE
GRN/BLK WIRE
GRY WIRE
IMMO DATA LINE
INJ 1 CTRL
INJ 2 CTRL
INJ 4 CTRL
INJECTOR 1
INJECTOR 2
INJECTOR 3
INJECTOR 4
MAIN RELAY CTRL
MEMORY PWR
ORG/ WIRE
ORG/BLK WIRE
PCM
PCSV CTRL
PNK WIRE
PNK/BLK WIRE
RED WIRE
START RLY CTRL HI
START RLY CTRL LO
STARTING/CHARGING SYSTEM
TMM MOTOR
VIS CTRL
W/ IMMOBILIZER
W/O IMMOBILIZER
WHT WIRE
WIPER SW IN
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l (5 of 7) -> MAIN RELAY CTRL
