Kia Rio IV facelift (2020-2024) ect sens 2 sig ect sens 1 gnd Wiring diagrams

This page contains all the electrical diagrams for the component. ect sens 2 sig ect sens 1 gnd, in which he is found in the car Kia Rio IV facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram ect sens 2 sig ect sens 1 gnd (1 of 3)

Wiring diagram ect sens 2 sig ect sens 1 gnd for Kia Rio IV facelift (2020-2024) (1 of 3)

Get access

A/C PRESSURE TRANSDUCER A/CON RLY CTRL BLK WIRE BLU WIRE BRN/ORG WIRE C-CAN HIGH C-CAN LOW C/FAN RLY CTRL HIGH C/FAN RLY CTRL LOW COMPUTER DATA LINES SYSTEM COOLING FAN 1 RELAY COOLING FAN 2 RELAY COOLING FAN FUSE COOLING FAN MOTOR E/R JUNCTION BLOCK ECT SENS 1 SIG ECT SENS 2 GND ECT SENS 2 SIG ECT SENS 1 GND ENGINE COOLANT TEMPERATURE SENSOR 1 ENGINE COOLANT TEMPERATURE SENSOR 2 GRY WIRE HOT AT ALL TIMES HOT W/ MAIN RELAY ENERGIZED ORG/ WIRE PCM PNK WIRE RED WIRE SENS GND SENS SIG SENS SPLY SENSOR FUSE WHT WIRE

Go to component -> Automatic a/c circuit (4 of 4) -> ECT SENS 2 SIG ECT SENS 1 GND

Wiring diagram ect sens 2 sig ect sens 1 gnd (2 of 3)

Wiring diagram ect sens 2 sig ect sens 1 gnd for Kia Rio IV facelift (2020-2024) (2 of 3)

Get access

A/T BLK WIRE BLU WIRE BRN/ORG WIRE C-CAN HIGH C-CAN LOW C/FAN RLY CTRL HIGH C/FAN RLY CTRL LOW COMPUTER DATA LINES SYSTEM COOLING FAN 1 RELAY COOLING FAN 2 RELAY COOLING FAN FUSE COOLING FAN MOTOR E/R JUNCTION BLOCK ECT SENS 1 SIG ECT SENS 2 GND ECT SENS 2 SIG ECT SENS 1 GND ENGINE COOLANT TEMPERATURE SENSOR 1 ENGINE COOLANT TEMPERATURE SENSOR 2 GRY WIRE HOT AT ALL TIMES HOT W/ MAIN RELAY ENERGIZED M/T ORG/ WIRE PCM (A/T) ECM (M/T) PNK WIRE RED WIRE SENSOR FUSE WHT WIRE

Go to component -> Cooling fan circuit -> ECT SENS 2 SIG ECT SENS 1 GND
