Kia Rio IV facelift (2020-2024) drv frt impact sens lo Wiring diagram
This page shows the only wiring diagram for the component.drv frt impact sens lo, which is found in the car Kia Rio IV facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv frt impact sens lo (1 of 1)
A/BAG IND FUSE
AIR BAG
AIR BAG FUSE
AIR BAG IND
BCM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN
C-CAN HI
C-CAN LO
CENTER FASCIA SWITCH
CLOCKSPRING
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CRASH OUTPUT
DRIVER AIR BAG
DRIVER FRONT IMPACT SENSOR
DRIVER SEAT BELT BUCKLE SWITCH
DRV FRT IMPACT SENS HI
DRV FRT IMPACT SENS LO
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
HOT IN ON OR START
I/P JUNCTION BLOCK
I/P-B
I/P-C
ILL
INSTRUMENT CLUSTER
MICOM
NCA WIRE
ON/START INPUT
ORG/ WIRE
PASS FRT IMPACT SENS HI
PASS FRT IMPACT SENS LO
PASSENGER AIR BAG 1
PASSENGER AIR BAG 2
PASSENGER AIR BAG OFF IND
PASSENGER FRONT IMPACT SENSOR
PASSENGER OCCUPANT DETECTION SENSOR
PNK/BLK WIRE
RED WIRE
SEAT BELT DRV SW
SEAT BELT IND
SRS CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE)
STEERING WHEEL)
TELLTALE
TRANSCEIVER/
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> DRV FRT IMPACT SENS LO
