Kia Rio IV facelift (2020-2024) a/v, navigation head unit Wiring diagram
This page shows the only wiring diagram for the component.a/v, navigation head unit, which is found in the car Kia Rio IV facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/v, navigation head unit (1 of 1)
A/V, NAVIGATION HEAD UNIT
AUDIO
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN TRANSCEIVER
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CRUISE IND
CRUISE SET IND
ETC MOTOR, THROTTLE POSITION SENSOR
GRN WIRE
GRY WIRE
HOT IN ON OR START
I/P JUNCTION BLOCK
I/P-C
INSTRUMENT CLUSTER
MICOM
MOTOR
PNK WIRE
PNK/BLK WIRE
RED WIRE
SIG 1 GND
SIG 3 GND
SPEED OUT
SPEEDOMETER
STANDARD DISPLAY UVO
TACHOMETER
THROTTLE POSITION
TRIP
TRIP SW(-)
VEH SPD
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (2 of 3) -> A/V, NAVIGATION HEAD UNIT
