Car Wiring Diagrams for Tailgate release circuit, 5 door for Kia Rio III facelift (2015-2017)

B-CAN HIGH B-CAN LOW BCM DOOR LOCK RELAY CTRL BLK WIRE BLU WIRE BRN WIRE BRN/ORG WIRE C-CAN CLUSTER FUSE COMPUTER DATA LINES SYSTEM DOOR LOCK RELAY DOOR LOCKS SYSTEM DR LOCK FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START I/P JUNCTION BOX I/P-B I/P-F INSTRUMENT CLUSTER LUGGAGE LAMP MICOM MOTOR ORG/ WIRE PNK WIRE POWER CONNECTOR RED WIRE ROOM LAMP FUSE TAIL GATE LOCK ACTUATOR TAIL GATE RELAY CTRL TAIL GATE SWITCH TAIL GATE UNLOCK RELAY TAILGATE SWITCH TRANSCEIVER LOW TRUNK OPEN IND W/ CENTRAL DOOR LOCK W/O CENTRAL DOOR LOCK WHT WIRE
