Kia Rio III facelift (2015-2017) right folding motor Wiring diagram
This page shows the only wiring diagram for the component.right folding motor, which is found in the car Kia Rio III facelift (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right folding motor (1 of 1)
ACC FUSE
BLK WIRE
BLU WIRE
DEFOGGER
DEFOGGER SYSTEM
DOWN
DRIVER POWER OUTSIDE MIRROR
FOLDING MIRR FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
I/P JUNCTION BOX
I/P-F
LEFT
LEFT FOLDING MOTOR
LEFT RIGHT
MIRROR FOLDING SWITCH
NCA WIRE
ORG/ WIRE
OUTSIDE MIRROR MOTOR
PASSENGER POWER OUTSIDE MIRROR
POWER OUTSIDE MIRROR SWITCH
RED WIRE
RIGHT
RIGHT FOLDING MOTOR
SELECTOR SWITCH
TURN LAMP
UP DOWN
UP/ DOWN LEFT/ RIGHT
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit, w/ fold-back mirrors -> RIGHT FOLDING MOTOR
