Tailgate release circuit, 5 door for Kia Rio III (2011-2015)
Tailgate release circuit, 5 door
BCM DOOR (UNDER UNLOCK LEFT RELAY SIDE OF CTRL DASH)
BCM DOOR UNLOCK RELAY CTRL
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
DOOR UNLOCK
DOOR UNLOCK RELAY
DR LOCK FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
I/P JUNCTION BOX
I/P-B
I/P-F
LUGGAGE LAMP
MOTOR
ORG/ WIRE
PNK WIRE
POWER CONNE- CTOR
RELAY
ROOM LP FUSE
TAIL GATE LOCK ACTUATOR
TAIL GATE MOTOR SWITCH
TAIL GATE RELAY CTRL
TAIL GATE SWITCH
TAIL GATE UNLOCK
TAIL GATE UNLOCK RELAY
W/ CENTRAL DOOR LOCK
W/O CENTRAL DOOR LOCK
W/O CENTRAL DOOR LOCK W/ CENTRAL DOOR LOCK
