Starting circuit, without smart key & with isg for Kia Rio III (2011-2015)
Starting circuit, without smart key & with isg
A/T
BATTERY
BATTERY, BATTERY FUSE BOX
BLK WIRE
BLK/ORG WIRE
BURGLAR ALARM RELAY
BURGLAR ALARM RELAY CONTROL BCM (UNDER LEFT SIDE OF DASH)
E/R JUNCTION BOX (ON LEFT SIDE OF ENGINE COMPT)
E/R-EGGGA
ECM/PCM (LEFT REAR OF ENGINE COMPT)
EGGG-AA EGGG-AK 8 47
FUSE
I/P JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
I/P-A
I/P-B
I/P-E
IGNITION LOCK SWITCH P/NSW
IGNITION SWITCH
LOCK
LOW DC-DC CONVERTER
M/T A/T
M/T A/T M/T
MOTOR (LEFT REAR OF ENGINE)
NCA WIRE
PCB FUSE, RELAY BOX (INTEGRAL TO ENGINE ROOM JUNCTION BOX)
PNK PNK PNK WIRE
PNK WIRE
RED WIRE
RELAY
RELAY RELAY CONTROL MONITORING
SIGNAL INPUT
SOLENOID
TRANSAXLE
W/ BURGLAR ALARM
W/O BURGLAR ALARM
WHT WIRE
YEL WIRE
