Kia Rio III (2011-2015) Computer data lines circuit

A/C CONTROL MODULE A/C CONTROL MODULE (AUTO A/C) A/T A/V, NAVIGATION A/V, NAVIGATION HEAD UNIT ABS 1 FUSE ALT FUSE ALT FUSE FUSE AUDIO BCM BCM (UNDER LEFT SIDE OF DASH) BLK WIRE BLU WIRE BRN WIRE COMPT) DATA LINK CONNECTOR DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) E/R JUNCTION BOX ECM (LEFT REAR OF ENGINE COMPT) EGGG-AK EGGG-MK FUSE HEAD UNIT HOT AT ALL TIMES HOT IN ON OR START I/P JUNCTION BOX I/P JUNCTION BOX (BEHIND LEFT SIDE OF DASH) I/P-B I/P-C I/P-E IMMOBILIZER MODULE IMMOBILIZER MODULE (W/O SMART KEY) INSTRUMENT CLUSTER M/T MULTI FUSE MULTI- MULTIPURPOSE CHECK CONNECTOR NAVIGATION PCM PCM (LEFT REAR OF ENGINE COMPT) PNK WIRE RED WIRE SMART KEY CONTROL MODULE SMART KEY CONTROL MODULE (IF EQUIPPED) STOP LAMP FUSE VEHICLE SPEED SENSOR VEHICLE SPEED SENSOR (TOP OF TRANSAXLE) YEL/ORG WIRE

A/C CONTROL MODULE AUTO A/C B-CAN LO B-CAN HI BCM BCM (UNDER LEFT SIDE OF DASH) BLU WIRE BOX (BEHIND LEFT SIDE OF DASH) BRN WIRE C-CAN LO C-CAN HI C-CAN LO C-CAN HI B-CAN LO B-CAN HI EPS CONTROL MODULE ESC MODULE ESC MODULE (RIGHT REAR OF ENGINE COMPT) I/P JUNCTION I/P JUNCTION BOX I/P-C I/P-E I/P-F INSTRUMENT CLUSTER INVERTER J/C MANUAL A/C MANUAL AUTO A/C A/C PASSENGER WEIGHT CLASSIFICATION SENSOR PASSENGER'S SEAT) RED WIRE RESISTOR HIGH SMART KEY CONTROL MODULE SRS CONTROL MODULE TIRE PRESSURE MONITORING MODULE TIRE PRESSURE MONITORING MODULE (BEHIND RIGHT SIDE OF DASH) W/ ISG, A/T WHT WIRE
