Kia Rio III (2011-2015) right map switch Wiring diagram
This page shows the only wiring diagram for the component.right map switch, which is found in the car Kia Rio III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right map switch (1 of 1)
BLK WIRE
BLU WIRE
BRN/ORG WIRE
CENTER ROOM LAMP
DOOR
DOOR ON
DOOR SWITCH
DOOR(-) GROUND
DOOR(-) SPOT(+)
DRIVER VANITY LAMP
DRIVER VANITY LAMP ON OFF
FRONT MAP LAMP
FUEL DOORS SYSTEM
GRN WIRE
GROUND
LED
LEFT DOOR MAP SWITCH SWITCH
LEFT MAP LAMP
LEFT MAP SWITCH
LUGGAGE LAMP
MEMORY POWER
MOTOR
OFF
ORG/ WIRE
PASSENGER VANITY LAMP
PASSENGER VANITY LAMP ON OFF
PNK WIRE
RED WIRE
RIGHT MAP LAMP
RIGHT MAP SWITCH
SPOT
TAIL GATE LOCK ACTUATOR
TAIL GATE SWITCH
TRUNK LID ACTUATOR
TRUNK ROOM LAMP SWITCH
TRUNK, TAILGATE,
TRUNK, TAILGATE, FUEL DOORS SYSTEM
W/ CENTRAL DOOR LOCK
W/ SUNROOF
W/O CENTRAL DOOR LOCK
W/O SUNROOF
W/O SUNROOF W/ SUNROOF
Go to component -> Courtesy lamp circuit (2 of 2) -> RIGHT MAP SWITCH
