Kia Rio III (2011-2015) relay signal control input Wiring diagrams
This page contains all the electrical diagrams for the component. relay signal control input, in which he is found in the car Kia Rio III (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
relay signal control input wiring diagram (1 of 2)
A/T
A/T M/T
BATTERY
BATTERY, BATTERY FUSE BOX
BLK WIRE
BLK/ORG WIRE
BURGLAR ALARM RELAY
BURGLAR ALARM RELAY CONTROL BCM (UNDER LEFT SIDE OF DASH)
E/R JUNCTION BOX (ON LEFT SIDE OF ENGINE COMPT)
E/R-EGGGA
E/R-EGGGA PCB FUSE, RELAY BOX (INTEGRAL TO ENGINE ROOM JUNCTION BOX)
ECM/PCM (LEFT REAR OF ENGINE COMPT)
FUSE
I/P JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
I/P-A
I/P-B
I/P-E
IGNITION LOCK SWITCH P/NSW
IGNITION SWITCH
LOCK
M/T A/T M/T
MOTOR (LEFT REAR OF ENGINE)
NCA WIRE
PNK PNK PNK WIRE
PNK WIRE
RANGE SWITCH
RED WIRE
RELAY
RELAY SIGNAL CONTROL INPUT
SOLENOID
TRANSAXLE
W/ BURGLAR ALARM
W/O BURGLAR ALARM
WHT WIRE
YEL WIRE
Go to component -> Starting circuit, without smart key & without isg -> RELAY SIGNAL CONTROL INPUT
relay signal control input wiring diagram (2 of 2)
A/T M/T
BATTERY
BATTERY, BATTERY FUSE BOX
BLK WIRE
BLK/ORG WIRE
E/R JUNCTION BOX (ON LEFT SIDE OF ENGINE COMPT)
E/R-EGGGA
ECM/PCM (LEFT REAR OF ENGINE COMPT)
FUSE
GRN WIRE
GRY WIRE
I/P JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
I/P-A
I/P-E
M/T A/T
MOTOR (LEFT REAR OF ENGINE)
NCA WIRE
PCB FUSE, RELAY BOX (INTEGRAL TO ENGINE ROOM JUNCTION BOX)
PNK WIRE
RED WIRE
RELAY
RELAY SIGNAL CONTROL INPUT
SMART KEY CONTROL MODULE (UNDER LEFT SIDE OF DASH)
SOLENOID
SSB SSB
STOP BUTTON SWITCH
STOP LAMP FEEDBACK SIGNAL SIGNAL
TRANSAXLE P/MSW RANGE SWITCH (TOP OF TRANSAXLE)
WHT WIRE
Go to component -> Starting circuit, with smart key & without isg -> RELAY SIGNAL CONTROL INPUT
