Kia Rio III (2011-2015) reader ic Wiring diagrams
This page contains all the electrical diagrams for the component. reader ic, in which he is found in the car Kia Rio III (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram reader ic (1 of 2)
A/T M/T
ANTENNA COIL
BLK WIRE
BLU/BLK WIRE
CLUSTER FUSE
COMPT)
COMPUTER DATA LINES SYSTEM
DOOR WARNING SWITCH
ECM/PCM (LEFT REAR OF ENGINE
EGGG-AK EGGG-MK
GRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES I/P JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
HOT IN ON OR START
I/P-A
I/P-B
I/P-C
IMMO IND
IMMOBILIZER MODULE (LEFT TOP OF DASH)
INPUT SIGNAL INTERFACE
INSTRUMENT CLUSTER
K-LINE SIGNAL
MICOM
MICRO CONTROLLER
NCA WIRE
ORG/ WIRE
PDM 2 FUSE
PNK WIRE
POWER
POWER CONNECTOR
READER IC
RED WIRE
REGULATION
REGULATOR
ROOM LP FUSE
SERIAL SIGNAL
SUPPLY
TCU FUSE
TRANSPONDER
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Immobilizer circuit, without smart key system -> READER IC
Wiring diagram reader ic (2 of 2)
