Kia Rio III (2011-2015) pnk on/start in Wiring diagram
This page shows the only wiring diagram for the component.pnk on/start in, which is found in the car Kia Rio III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk on/start in (1 of 1)
B-CAN
BATTERY PWR
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN
C-CAN HI
C-CAN LO
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
EPS CONTROL MODULE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P JUNCTION BOX
I/P JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
I/P-B
I/P-C
INSTRUMENT CLUSTER
LEFT/RIGHT FRONT TIRE PRESSURE SENSOR
LEFT/RIGHT REAR TIRE PRESSURE SENSOR
MICOM
ON/START IN
PNK ON/START IN WIRE
PNK WIRE
POWER CONNECTOR
RED WIRE
RESISTOR
ROOM LP FUSE
TIRE PRESSURE MONITORING MODULE
TIRE PRESSURE MONITORING MODULE (BEHIND RIGHT SIDE OF DASH)
TPMS TREAD IND
TRANSCEIVER/
WHT WIRE
Go to component -> Tire pressure monitoring circuit -> PNK ON/START IN WIRE
