Kia Rio III (2011-2015) pnk eggg-aa wiring diagram
This page shows the only wiring diagram for the component.pnk eggg-aa, which is found in the car Kia Rio III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
pnk eggg-aa wiring diagram (1 of 1)
A/T
A/V, NAVIGATION HEAD UNIT
ATM SHIFT LEVER ILL
AUDIO
B/UP LP FUSE
BACK UP LAMP
BACK-UP LAMP SWITCH
BACK-UP LAMP SWITCH (TOP OF TRANSAXLE)
BCM
BCM (UNDER LEFT SIDE OF DASH)
BLK WIRE
BRN WIRE
E/R-EGGGB
EGGG-AA
ENGINE ROOM JUNCTION BOX
GRN WIRE
HOT IN ON OR START
I/P JUNCTION BOX
I/P JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
I/P-E
IND
LEFT REAR COMBINATION LAMP (IN)
LEFT REAR COMBINATION LAMP (IN) BACK-UP LAMP
M/T
NAVIGATION
NCA WIRE
ON/START INPUT
ORG/ WIRE
PCB FUSE, RELAY BOX
PCB FUSE, RELAY BOX (INTEGRAL TO
PCM
PCM (LEFT REAR OF ENGINE COMPT)
PNK EGGG-AA WIRE
PNK WIRE
POSI SW CODE
R IND
RED WIRE
RIGHT REAR COMBINA- TION LAMP (IN)
RIGHT REAR COMBINATION LAMP (IN)
RIGHT REAR COMBINATION LAMP (IN) BACK-UP LAMP
SIG (1)
SIG (2)
SIG 3
SIG 4
TCU FUSE
TRANSAXLE RANGE SWITCH
TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE)
UVO AUDIO
UVO AUDIO NAVIGATION
Go to component -> Back-up lamps circuit -> PNK EGGG-AA WIRE
