Kia Rio III (2011-2015) key unlk key lock Wiring diagrams

This page contains all the electrical diagrams for the component. key unlk key lock, in which he is found in the car Kia Rio III (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

key unlk key lock wiring diagram (1 of 2)

BCM BCM (UNDER LEFT SIDE OF DASH) BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/ORG WIRE BURGLAR ALARM BURGLAR ALARM HORN BURGLAR ALARM HORN RELAY BURGLAR ALARM HORN RLY CTRL DRIVER DOOR LOCK ACTUATOR (REAR OF LEFT FRONT DOOR) DRIVER DR KEY LK SIG DRIVER DR KEY UNLK SIG DRIVER DR LK/UNLK SIG E/R-EGGGA GRN WIRE GRY WIRE HOOD SW HOOD SWITCH HORN FUSE HORN RELAY HOT AT ALL TIMES KEY LOCK KEY UNLK KEY UNLK KEY LOCK KEY UNLK KEY LOCK LOCK LEFT REAR DOOR LOCK ACTUATOR LOCK LR DR LK/UNLK SIG NCA WIRE ORG/ WIRE PASS DR KEY UNLK SIG PASS DR LK/UNLK SIG PASSENGER DOOR LOCK ACTUATOR PCB FUSE, RELAY BOX PCB FUSE, RELAY BOX (INTEGRAL TO ENGINE PNK WIRE ROOM JUNCTION BOX) RR DR LK/UNLK SIG UNLK UNLK LOCK W/ BURGLAR ALARM W/O BURGLAR ALARM YEL WIRE

Go to component -> Forced entry circuit (1 of 2) -> KEY UNLK KEY LOCK

key unlk key lock wiring diagram (2 of 2)

Go to component -> Power door locks circuit (1 of 2) -> KEY UNLK KEY LOCK
