Kia Rio III (2011-2015) hot at all times fold'g mirr fuse Wiring diagram
This page shows the only wiring diagram for the component.hot at all times fold'g mirr fuse, which is found in the car Kia Rio III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot at all times fold'g mirr fuse (1 of 1)
BLK WIRE
BLU WIRE
DOWN
DRIVER POWER OUTSIDE MIRROR
FUSE
GRN WIRE
HOT AT ALL TIMES FOLD'G MIRR FUSE
HOT IN ACC OR ON
I/P JUNCTION BOX
I/P-F
LEFT
LEFT CTOR SWITCH
LEFT OUTSIDE MIRROR FOLDING MOTOR MOTOR
LEFT RIGHT
LEFT/ RIGHT UP/ DOWN
MIRROR FOLD- ING SWITCH UF
NCA WIRE
ORG/ WIRE
OUTSIDE MIRROR MOTOR
PASSENGER POWER OUTSIDE MIRROR
POWER OUTSIDE MIRROR SWITCH
RED WIRE
RIGHT
RIGHT FOLDING MOTOR
SELE-
SELE- RIGHT CTOR SWITCH
UP DOWN DOWN UP
UP/ DOWN LEFT/ RIGHT
VL HL
VR HR
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit, with fold-back mirrors -> HOT AT ALL TIMES FOLD'G MIRR FUSE
