Kia Rio III (2011-2015) driver pressure side impact sensor Wiring diagram
This page shows the only wiring diagram for the component.driver pressure side impact sensor, which is found in the car Kia Rio III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver pressure side impact sensor (1 of 1)
32 33 HIGH LOW LOW GROUND LOW LOW HIGH HIGH
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
DRIVER CURTAIN AIR BAG
DRIVER PRESSURE SIDE IMPACT SENSOR
DRIVER PRESSURE SIDE IMPACT SENSOR (DRIVER'S DOOR)
DRIVER SEAT BELT ANCHOR PRETENSIONER
DRIVER SEAT BELT BUCKLE SWITCH
DRIVER SEAT BELT PRETENSIONER
DRIVER SIDE AIR BAG
DRIVER SIDE IMPACT SENSOR
DRIVER SIDE IMPACT SENSOR (BASE OF LEFT "B" PILLAR)
DRIVER'S DOOR
GRN WIRE
GRN/BLK WIRE
GROUND
HIGH HIGH
HIGH HIGH HIGH HIGH HIGH HIGH HIGH HIGH 15 16 17 18
LOW LOW LOW LOW LOW LOW LOW LOW 2 3
ORG/BLK WIRE
PASSENGER CURTAIN AIR BAG
PASSENGER PRESSURE SIDE IMPACT SENSOR
PASSENGER PRESSURE SIDE IMPACT SENSOR (IN PASSENGER'S DOOR)
PASSENGER SEAT BELT ANCHOR PRETENSIONER
PASSENGER SEAT BELT BUCKLE SWITCH
PASSENGER SEAT BELT PRETENSIONER
PASSENGER SIDE AIR BAG
PASSENGER SIDE IMPACT SENSOR
PASSENGER SIDE IMPACT SENSOR (BASE OF RIGHT "B" PILLAR)
RED WIRE
RED/BLK WIRE
SRS CONTROL MODULE
SRS CONTROL MODULE (UNDER CENTER CONSOLE)
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> DRIVER PRESSURE SIDE IMPACT SENSOR
