Kia Rio III (2011-2015) driver dr key unlk sig Wiring diagrams

This page contains all the electrical diagrams for the component. driver dr key unlk sig, in which he is found in the car Kia Rio III (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram driver dr key unlk sig (1 of 2)

Wiring diagram driver dr key unlk sig for Kia Rio III (2011-2015) (1 of 2)

Get access

BCM BCM (UNDER LEFT SIDE OF DASH) BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/ORG WIRE BURGLAR ALARM BURGLAR ALARM HORN BURGLAR ALARM HORN RELAY BURGLAR ALARM HORN RLY CTRL DRIVER DOOR LOCK ACTUATOR (REAR OF LEFT FRONT DOOR) DRIVER DR KEY LK SIG DRIVER DR KEY UNLK SIG DRIVER DR LK/UNLK SIG E/R-EGGGA GRN WIRE GRY WIRE HOOD SW HOOD SWITCH HORN FUSE HORN RELAY HOT AT ALL TIMES KEY LOCK KEY UNLK KEY UNLK KEY LOCK KEY UNLK KEY LOCK LOCK LEFT REAR DOOR LOCK ACTUATOR LOCK LR DR LK/UNLK SIG NCA WIRE ORG/ WIRE PASS DR KEY UNLK SIG PASS DR LK/UNLK SIG PASSENGER DOOR LOCK ACTUATOR PCB FUSE, RELAY BOX PCB FUSE, RELAY BOX (INTEGRAL TO ENGINE PNK WIRE ROOM JUNCTION BOX) RR DR LK/UNLK SIG UNLK UNLK LOCK W/ BURGLAR ALARM W/O BURGLAR ALARM YEL WIRE

Go to component -> Forced entry circuit (1 of 2) -> DRIVER DR KEY UNLK SIG

Wiring diagram driver dr key unlk sig (2 of 2)

Wiring diagram driver dr key unlk sig for Kia Rio III (2011-2015) (2 of 2)

Get access

Go to component -> Power door locks circuit (1 of 2) -> DRIVER DR KEY UNLK SIG
