Kia Rio III (2011-2015) dot matrix lcd Wiring diagram
This page shows the only wiring diagram for the component.dot matrix lcd, which is found in the car Kia Rio III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dot matrix lcd (1 of 1)
A/V, NAVIGATION HEAD UNIT
ABS IND.
ACTIVE ECO
AIR BAG IND
ALT L OUT
ANTI-THEFT SYSTEM
AUTO STOP IND (GREEN/YELLOW)
B-CAN TRANSCEIVER
BATTERY
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE IND
BRN WIRE
BRN/ORG WIRE
C-CAN TRANSCEIVER
CHARGE
CHARGE IND
CLUSTER FUSE
CLUSTER GROUND
CLUSTER SIGNAL
COMPUTER DATA LINES SYSTEM
CONSTANT CURRENT CIRCUIT
CRUISE CONTROL SYSTEM
CRUISE IND
DIAL ILL
DOOR OPEN IND
DOT MATRIX LCD
EBD/PARKING
ECO IND (GREEN/WHITE/RED) WIRE
EEPROM
ENGINE CHECK IND
ENGINE CONTROLS SYSTEM
EPS IND
ESC IND
ESC OFF IND
FRONT FOG IND
FUEL
FUEL GAUGE
FUEL INPUT
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
HEADLIGHTS SYSTEM
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN ON OR START
I/P JUNCTION BOX
I/P-B
ILL
IMMO IND
INSTRUMENT CLUSTER
LCD CONTROL CIRCUIT
LCD ILL
LOW BEAM IND
LOW DC-DC CONVERTER
LOW FUEL IND
M/T
M/T N
MICOM
OIL PRESSURE
OIL PRESSURE IND
ORG/ WIRE
OUT
PARKING BRAKE
PNK WIRE
POINTER ILL
POWER CONNECTOR
POWER GROUND
RED WIRE
RED/BLK WIRE
REGULATOR
RHEOSTAT DETENT
RHEOSTAT DOWN
RHEOSTAT OUT
RHEOSTAT UP
ROOM LP FUSE
SEAT BELT IND
SET IND
SIGNAL GROUND
SPEED
SPEEDO- METER
STARTING/CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHO- METER
TAIL ON IND
TEMP GAUGE
TPMS TREAD IND
TRANSMISSIONS SYSTEM
TRUNK OPEN IND
TURN LEFT IND
TURN RIGHT IND
W/ ISG
WHT WIRE
YEL (OR YEL/ORG) WIRE
YEL WIRE
Go to component -> Instrument cluster circuit, w/ super vision (1 of 2) -> DOT MATRIX LCD
