Kia Rio III (2011-2015) b-can transceiver low high Wiring diagram
This page shows the only wiring diagram for the component.b-can transceiver low high, which is found in the car Kia Rio III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram b-can transceiver low high (1 of 1)
ALT FUSE
ALTERNATOR
ALTERNATOR (LEFT FRONT OF ENGINE)
ALTERNATOR COM
ALTERNATOR PWM
AMS FUSE
B-CAN
B-CAN TRANSCEIVER LOW HIGH
BATTERY
BATTERY SENSOR
BATTERY SNSR + SENSOR (LEFT REAR OF ENGINE COMPT) LIN LINE
BATTERY, BATTERY FUSE BOX
BLK WIRE
BLU WIRE
BOX (BEHIND LEFT SIDE OF DASH)
BRN WIRE
C-CAN TRANSCEIVER
C-CAN TRANSCEIVER LOW HIGH
CHARGE IND
CLUSTER FUSE
COM
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BOX
E/R JUNCTION BOX (ON LEFT SIDE OF ENGINE COMPT)
ECM/PCM
ECM/PCM (LEFT REAR OF ENGINE COMPT)
EGGG-AA
EGGG-AK
EGGG-MA
EGGG-MA EGGG-AK 57 16
EGGG-MK
EGGG-MK EGGG-AA 24 51
EGGG-MK EGGG-AK 61 62
FR COM
GRN WIRE
GRY WIRE
HIGH LOW
HOT IN ON OR START
I/P JUNCTION
I/P JUNCTION BOX
I/P-B
INSTRUMENT CLUSTER
LIN COMMUNICATION
LIN LINE
M/T A/T
MICOM
MULTI FUSE
PNK WIRE
RED WIRE
SNSR
TRANSCEIVER/
WHT WIRE
YEL WIRE
Go to component -> Charging circuit -> B-CAN TRANSCEIVER LOW HIGH
