Kia Rio III (2011-2015) 9 10 h/lp lo sw drl enable Wiring diagram
This page shows the only wiring diagram for the component.9 10 h/lp lo sw drl enable, which is found in the car Kia Rio III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 9 10 h/lp lo sw drl enable (1 of 1)
12 10 H/LP HI SW FRONT FOG LP SW ON
26 19 25 ON/START IN H/LP LO SIG DEDICATED DRL LP
6 7 8 H/LP RLY CTRL LO H/LP RLY CTRL HI FRONT FOG LP RLY CTRL
7 8 9 10 6 4 B-CAN HI B-CAN LO POWER SIG GND AUTO LIGHT SW
9 10 H/LP LO SW DRL ENABLE
AUTO
AUTO LIGHT SENSOR
BCM (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DASH PANEL)
DIMMER, PASSING SWITCH
E/R-EGGGA
E/R-EGGGB
FRONT FOG LAMP SWITCH
GRY WIRE
GRY/BLK WIRE
H/LP FUSE
H/LP HI FUSE
HEAD LAMP (LO) RELAY
HEAD TAIL OFF AUTO OFF
HEAD- LAMP HI RELAY
HOT AT ALL TIMES
LEFT H/LP FUSE RIGHT H/LP FUSE
LEFT HEAD LAMP DRL LAMP
LIGHT SWITCH
LOW LOW PASS HIGH PASS HIGH
MULTIFUNCTION SWITCH
NCA WIRE
ON OFF
ORG/ WIRE
PCB FUSE, RELAY BOX (INTEGRAL TO ENGINE ROOM JUNCTION BOX)
PNK 5 6 7 WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RIGHT HEAD LAMP DRL LAMP HI LO
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, with drl (1 of 2) -> 9 10 H/LP LO SW DRL ENABLE
