Kia Rio III (2011-2015) 1 2 3 4 5 6 7 8 9 computer c-can high c-can low data lines system Wiring diagram
This page shows the only wiring diagram for the component.1 2 3 4 5 6 7 8 9 computer c-can high c-can low data lines system, which is found in the car Kia Rio III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 3 4 5 6 7 8 9 computer c-can high c-can low data lines system (1 of 1)
1 2 3 4 5 6 7 8 9 COMPUTER C-CAN HIGH C-CAN LOW DATA LINES SYSTEM
BLK WIRE
BLK/ORG WIRE
BLU WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BOX
GRN WIRE
HALL SENS GND
HALL SENS POWER
HALL SENS SIG U
HALL SENS SIG V
HALL SENS SIG W
HOT AT ALL TIMES
HOT AT ALL TIMES E/R JUNCTION INVERTER BOX FUSE (ON LEFT SIDE OF ENGINE COMPT)
HOT IN ON OR START
I/P JUNCTION
I/P JUNCTION BOX
I/P-E
INVERTER
INVERTER FUSE
MEMORY POWER
MOTOR POWER U
MOTOR POWER V
MOTOR POWER W
OIL PUMP MOTOR
ON/START INPUT
PCU BOX FUSE (BEHIND LEFT SIDE OF DASH)
PCU FUSE
PNK WIRE
POWER
RED WIRE
SHIELD GND
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l, electric oil pump circuit -> 1 2 3 4 5 6 7 8 9 COMPUTER C-CAN HIGH C-CAN LOW DATA LINES SYSTEM
