Car Wiring Diagrams for Heated seats circuit for Kia Rio II facelift (2009-2011)

BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE GRN WIRE GRN/ORG WIRE HOT IN ON I/P JUNCTION BOX (UNDER LEFT SIDE OF DASH, I/P-K ILLUM IND LEFT SEAT WARMER (IN DRIVER'S SEAT) LEFT SEAT WARMER SWITCH NCA WIRE ORG/ WIRE PNK WIRE RED WIRE RED/ORG WIRE RIGHT SEAT WARMER (IN FRONT PASSENGER'S SEAT) RIGHT SEAT WARMER SWITCH S/HTD FUSE YEL WIRE
