Kia Rio II facelift (2009-2011) right power outside mirror motor (in front Wiring diagram
This page shows the only wiring diagram for the component.right power outside mirror motor (in front, which is found in the car Kia Rio II facelift (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right power outside mirror motor (in front (1 of 1)
BCM (UNDER RIGHT SIDE OF DASH)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
DEFOGGER
DEFOGGER TIMER (UNDER LEFT SIDE OF DASH)
ECM/PCM (ECM: LEFT REAR OF ENGINE COMPT)
ENGINE RUNNING INPUT SIGNAL
GROUND
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON
HTD GLASS FUSE
HTD MIR FUSE
I/P-A
I/P-G
I/P-K
I/P-M
IGN FUSE
ILLUMINATION
IND
INSTRUMENT PANEL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
JOINT CONNECTOR
LEFT POWER OUTSIDE MIRROR MOTOR (IN DRIVER'S DOOR MIRROR)
M/T A/T
NCA WIRE
ON INPUT
ORG/ WIRE
PASSENGER'S DOOR MIRROR)
PNK/BLK WIRE
REAR DEFOGGER RELAY CONTROL
REAR DEFOGGER SWITCH
REAR DEFOGGER SWITCH INPUT
REAR WINDOW DEFOGGER (5 DOOR : LEFT, RIGHT SIDE OF TAILGATE WINDOW)
RED WIRE
RIGHT POWER OUTSIDE MIRROR MOTOR (IN FRONT
RR HTD RELAY
STARTING/ CHARGING SYSTEM
W/ BCM
W/O BCM
YEL WIRE
Go to component -> Defoggers circuit -> RIGHT POWER OUTSIDE MIRROR MOTOR (IN FRONT
