Kia Rio II facelift (2009-2011) 32 33 immobilizer ind sensor heating sensor heating fuel pump ctrl injector 3 Wiring diagram
This page shows the only wiring diagram for the component.32 33 immobilizer ind sensor heating sensor heating fuel pump ctrl injector 3, which is found in the car Kia Rio II facelift (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 32 33 immobilizer ind sensor heating sensor heating fuel pump ctrl injector 3 (1 of 1)
15 16 17 18 SENSOR `A' CYL 3 CYL 1
32 33 IMMOBILIZER IND SENSOR HEATING SENSOR HEATING FUEL PUMP CTRL INJECTOR 3
42 43 SENSOR POWER SENSOR POWER IMMO LINE WHEEL SPEED IN
5 6 7 8 PNK ACTUATOR CTRL FUEL CAP CPV CONTROL MAIN RLY CTRL WIRE
55 56 57 58 SENSOR `B' BATT VOLTAGE POWER SENSOR POWER
AIR CONDITIONING SYSTEM
ANTI-THEFT SYSTEM
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
CAN LOW
CANISTER PURGE CONTROL VALVE (LEFT REAR OF ENGINE COMPT)
CANISTER VALVE A/C RLY CTRL
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
CRANKSHAFT POSITION SENSOR (REAR OF ENGINE)
CVVT OIL CONTROL VALVE (LEFT REAR OF CYLINDER HEAD)
CYL 2 CYL 4 SENSOR SIGNAL 2 3
FAN RELAY CTRL ACTUATOR CTRL FAN RELAY CTRL SIGNAL OUT TACHOMETER 22 23
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
IDLE SPEED CONTROL ACTUATOR (TOP RIGHT REAR OF ENGINE)
INJECTOR 1 (ON INTAKE MANIFOLD)
INJECTOR 4 CVVT OIL INJECTOR 1 OUTPUT IND LAMP INJECTOR 2 PNK WIRE
INJECTORS (ON INTAKE MANIFOLD)
NCA WIRE
ORG/ WIRE
PCM
PNK 2 3 WIRE
PNK ON/START INPUT CAN HIGH 12 13 WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RIGHT FRONT WHEEL SENSOR (W/O ABS)
SENSOR A
SENSOR B
WHEEL SPEED IN
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l, a/t (5 of 5) -> 32 33 IMMOBILIZER IND SENSOR HEATING SENSOR HEATING FUEL PUMP CTRL INJECTOR 3
