Back-up lamps circuit for Kia Rio II (2005-2009)

Back-up lamps circuit

Get access

12 PNK I/P-F WIRE 4 5 (5 DOOR) (4 DOOR) 5 DOOR 5 DOOR 4 DOOR A/T B/UP LP FUSE BACK UP LAMP BACK-UP LAMP SWITCH (ON TRANSAXLE REAR COVER) BLK WIRE BLU WIRE GRN WIRE HOT IN ON OR START I/P JUNCTION BOX (UNDER LEFT SIDE OF DASH, I/P-E I/P JUNCTION BOX (UNDER LEFT SIDE OF DASH) I/P-B INSTRUMENT CLUSTER LEFT REAR COMBINATION LAMP BACK UP LAMP M/T NCA WIRE ORG/ WIRE PNK WIRE RED WIRE RIGHT REAR COMBINATION LAMP TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE) WHT/BLK WIRE
