Kia Rio II (2005-2009) wip on wash on Wiring diagram

This page shows the only wiring diagram for the component.wip on wash on, which is found in the car Kia Rio II (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram wip on wash on (1 of 1)

Wiring diagram wip on wash on for Kia Rio II (2005-2009)

Get access

BLK WIRE BRN WIRE FRONT WIPER/WASHER CIRCUIT GRY WIRE HOT IN ON I/P JUNCTION BOX (UNDER LEFT SIDE OF DASH, I/P-A I/P-M PNK WIRE MULTIFUNCTION SWITCH OFF ORG/ WIRE R/WPR FUSE REAR WIPER MOTOR (CENTER OF TAILGATE) REAR WIPER/ WASHER SWITCH WASHER MOTOR (RIGHT FRONT OF ENGINE COMPT) WHT WIRE WIP ON WASH ON

Go to component: -> Rear wiper/washer circuit -> WIP ON WASH ON
