Kia Rio II (2005-2009) right power outside Wiring diagram
This page shows the only wiring diagram for the component.right power outside, which is found in the car Kia Rio II (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right power outside (1 of 1)
A/T
BLK WIRE
DATA LINK CONNECTOR
FRONT POWER WINDOW
FRONT, REAR POWER WINDOW
HIGH MOUNTED STOP LAMP
IGNITION COIL SHIELD
IMMOBILIZER CONTROL MODULE
JOINT CONNECTOR
KNOCK SENSOR SHIELD
LAMP
LEFT LICENSE
M/T
MIRROR MOTOR
MOTOR
NCA WIRE
PCM
REAR WIPER
RELAY BOX
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT FRONT DOOR UNLOCK SWITCH
RIGHT FRONT POWER WINDOW SWITCH
RIGHT LICENSE
RIGHT POWER OUTSIDE
SENSOR
SWITCH
TAIL GATE LOCK ACTUATOR
TAIL GATE UNLOCK SWITCH
TRANSAXLE RANGE
VEHICLE SPEED
Go to component: -> Ground distribution circuit (3 of 3) -> RIGHT POWER OUTSIDE
