Kia Rio II (2005-2009) ground memory power pnk Wiring diagram
This page shows the only wiring diagram for the component.ground memory power pnk, which is found in the car Kia Rio II (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground memory power pnk (1 of 1)
5 DOOR
AM/ FM
AMP FUSE
AMPLIFIER (4 DOOR: RIGHT SIDE OF TRUNK) (5 DOOR: AT RIGHT "C" PILLAR)
ANTENNA (BEHIND RIGHT SIDE OF DASH)
ANTENNA PNK 1 WIRE
AUDIO
AUDIO FUSE
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
CIRCUIT
F/CABLE
GRN WIRE
GROUND MEMORY POWER PNK WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
I/P JUNCTION BOX (UNDER LEFT SIDE OF DASH,
I/P-A
I/P-G
I/P-M
LEFT FRONT DOOR SPEAKER
LEFT FRONT TWEETER SPEAKER
LEFT REAR SPEAKER (4 DOOR) LEFT REAR DOOR SPEAKER
NCA WIRE
ORG/ WIRE
PNK B+ (ACC/ON) GROUND WIRE
POWER CONNECTOR
RED WIRE
RIGHT FRONT TWEETER SPEAKER RIGHT FRONT DOOR SPEAKER
SIGNAL INPUT
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, with amplifier -> GROUND MEMORY POWER PNK WIRE
