Power windows circuit, with rear power windows for Kia Rio I facelift (2002-2005)
Power windows circuit, with rear power windows
AUTO UP/DOWN CONTROL
BLK WIRE
BLU WIRE
DOWN
ETWIS
GRN WIRE
HOT AT ALL TIMES
J/C 10
JC-04
LEFT FRONT POWER WINDOW MOTOR
LEFT REAR
LEFT REAR POWER WINDOW MOTOR
LOCK SWITCH
MAIN FUSE BOX (AT LEFT REAR OF ENGINE COMPARTMENT)
P/WIN FUSE
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY (IN MAIN FUSE BOX)
POWER WINDOW SWITCH
RED WIRE
RED/WHT WIRE
RIGHT FRONT POWER WINDOW MOTOR
RIGHT FRONT POWER WINDOW SWITCH
RIGHT REAR POWER WINDOW
RIGHT REAR POWER WINDOW MOTOR
SWITCH
WHT WIRE
YEL WIRE
