Ground distribution circuit for Kia Rio I facelift (2002-2005)

Ground distribution circuit (1 of 2)

Rio Kia I facelift (2002-2005): Ground distribution circuit (1 of 2)

Get access

4 BUTTON ABS, EBO RELAY FLASHER UNIT AIR BAG UNIT BLOWER SWITCH AIR CON DEFROSTER SWITCH AIR CON MAIN SWITCH AUDIO BATTERY BLK WIRE BRAKE FLUID SWITCH CIGAR LIGHTER COMBINATION SWITCH DOOR LOCK RELAY DRL UNIT ETWIS FOG LAMP SWITCH FRONT WIPER MOTOR FUEL PUMP UNIT ABS UNIT GROUND JOINT CONNECTOR JC-08 JOINT CONNECTOR JC-10 KEYLESS RECEIVER MAP LAMP NCA WIRE POWER MIRROR SWITCH POWER WINDOW MAIN SWITCH REAR WIPER, WASHER SWITCH BLOWER MOTOR RELAY PANEL LIGHT SWITCH AUTO CLOCK RIGHT POWER MIRROR HEATER SEAT HEATER SEAT WARMER SWITCH INSTRUMENT CLUSTER SHIFT LOCK UNIT SEAT BELT SWITCH MODE SWITCH SHORT CONNECTOR JC-04 SPEED SENSOR TO JOINT CONNECTOR JC-12 (DIAGRAM 2 OF 2)

Ground distribution circuit (2 of 2)

Rio Kia I facelift (2002-2005): Ground distribution circuit (2 of 2)

Get access

5 DOOR B-01 BACK DOOR LOCK MOTOR BLK WIRE BLK/BLU WIRE BLU WIRE CONDENSER FAN MOTOR CONDENSER FAN RELAY DIAGNOSIS CONNECTOR ENGINE CONTROL MODULE FROM JOINT CONNECTOR JC-10 (DIAGRAM 1 OF 2) HIGH MOUNT STOP LIGHT JOINT CONNECTOR JC-12 LEFT FOG LAMP LEFT FRONT COMBINATION LAMP LEFT HEADLIGHT LEFT REAR COMBINATION LAMP RIGHT REAR COMBINATION LAMP OBD II CONNECTOR RIGHT FOG LAMP RIGHT FRONT COMBINATION LAMP RIGHT HEADLIGHT RIGHT LICENSE LIGHT STARTER RELAY HORN TRANSMISSION CONTROL MODULE WASHER MOTOR BURGLAR HORN
